Planeck

Product Description

Designer ceiling air-conditioning cassettes with mixed air function. Suitable for installation in suspended ceilings.

Key Features

• Only 5 cm overall unit height: aesthetically pleasing and unobtrusive.
• Recirculating and mixed air models: identical appearance with a ceiling installation depth of only 360 mm.
• Discharges on 3 sides, therefore ideal for fitting close to the wall.
• Particularly energy-efficient with infinitely variable speed control.

Your Benefits

• Ceiling cassette with genuine mixed air function.
• Continuously variable single-phase control.
• Easy to maintain thanks to hingeddesigner casing.

Technology

• Horseshoe-shaped Cu/Al heat exchanger for heating or cooling with LPHW or LPCW.
• Heat exchanger enables a lateral fresh air supply and flat design.
• Air flow-optimised plastic radial fan.
• Integral G2 recirculating air filter.
• Cooling model with condensation tray and condensation pump.
• Optional infinitely variable speed control for a CO2-managed fresh air supply and/or demand-optimised heating/cooling operation.

Areas of application/installation

• Showrooms and sales floorsand retail chains with one or more unit.
• With room heights of approx. 2.3 – 3.3 m.
• For recirculating and mixed air operation.
• All round support for easy fitting of the suspended ceiling

Also good to know

• EU design protected air grille that can be hinged down for easy maintenance.
• In RAL 9016, other colours optional.
• Mixed air model with integral mixed air flap.
• Compatible with Kampmann accessories programme, e.g. KaControl technology for the recirculating air model.
• Optional: EC fan design and motorised adjustable louvres for heating/cooling.
